The other day I was at lunch with my customer architect at Chef. We were talking about our situation. Our reference architecture fits Chef’s reference architecture from about a year ago, which consists of a Chef Server and an Analytics Server as the core solution. Change takes a while, so I had been delaying setting up a Chef Automate environment before I got some other things accomplished.

However, at lunch we both were convinced that a Chef Visibility node could easily replace a Chef Analytics node and set our teams up better for where Chef is going. We would set the server up in a POC mode which would mean we had no real backup plan, but that’s OK because we are not really using Chef Analytics in a useful way.

This strategy is pretty typical of one I’ve used lately: let people see what you’re talking about and interact with it, even if it’s not in the perfect final state. Then, with experience as a guide, take the next step the right way. We will likely end up with a central Visibility server, but I don’t want to risk everything just to make that happen. So we set this up instead and move things forward.

After the discussion with my customer architect, Thomas Cate helped me come up with this guide. I wrote everything down and thought it might be good to share with the community, in case anyone else was thinking of going this way.

Migration Steps

This will migrate an existing Chef Analytics Server to a Chef Visibility Server in POC mode.

Back up your keys on the analytics server

We’re getting ready to uninstall Analytics, but we want to keep the keys because we’ll use them later.

• Find the key location in /etc/opscode-analytics/opscode-analytics.rb. The keys will likely be located in /etc/pki/tls/certs and /etc/pki/tls/private
• Back up the keys to ~/cert-backup

Clean and uninstall Chef Analytics

Let’s get rid of analytics now:

• Run opscode-analytics-ctl cleanse
• Run opscode-analytics-ctl stop
• Remove the package yum remove opscode-analytics
• Run sudo rm -rf /opt/opscode-analytics
• Reboot server sudo reboot now

Remove Analytics from the Chef Server

On the Chef Server,

• open /etc/opscode/chef-server.rb and comment out ocid for analytics
• run chef-server-ctl reconfigure

Install Automate

• Navigate to the downloads page and copy the appropriate link
• On the Analytics Server, wget that link to download it to the user home, for example: wget https://packages.chef.io/stable/el/7/delivery-0.5.370-1.el7.x86_64.rpm for my CentOS box
• Install the package, on CentOS: sudo rpm -Uvh delivery-0.5.370-1.el6.x86_64.rpm. When it asks you to configure the Delivery Server, say no

Set up Licensing

You’ll need to get a delivery.license from a friend at Chef. You also get your pem key for your Chef Server as a one-time use to authenticate to it and add workflow stuff. I’m not using that, so this was not really needed, but you know, we do it anyway.

Run sudo delivery-ctl setup --license ~/delivery.license --key ~/[your-name].pem --server-url https://[your-chef-server]/organizations/[your-org] --fqdn analytics.[your-domain].com

• When it asks for an organization, use your company name. The organization can be the same for different visibility servers. In fact, one can argue in this situation it’s quite useless; it’s more for multi-tenancy.

You should probably copy the server-url from your knife.rb file.

Finalize installation

• run sudo delivery-ctl reconfigure
• check that the settings in /etc/delivery/delivery.rb are good (especially the FQDN)

Set up certificates

Now it’s time to reuse your certificates that you backed up earlier.

• Put the ssl certs in place /var/opt/delivery/nginx/ca - Important: these files need to same name as what is there by default. So you should copy by name and change the file name of what you had before.
• Restart nginx sudo delivery-ctl restart nginx
• Make sure it’s working with delivery-ctl status

Set up an Admin User

• Run delivery-ctl create-enterprise [enterprise] --ssh-pub-key-file=/etc/delivery/builder_key.pub

This will generate user information that will be output to your command line:

Created enterprise: company-name
Admin username: admin
Admin password: password-here
Builder Password: builder-password-here
Web login: https://analytics.mycompany.com/e/companyname/

Navigate to that web login and you should see the automate login. Login with admin and the password it gives you.

Set up more users

At this point you can change the admin password to something you can remember and add users. This has to be separate from the Chef Server because there are many Chef Servers to one Visibility Server. Well, not in this case, but that’s the design.

So you have two options:

1. Set up a bunch of users manually
2. Set up LDAP authentication following these directions

Configure Data Collector on Chef Visibility server

Now I’m going to set up a token for configuring a data collector for my clients to talk to the Chef Visibility server:

• Create a Guid (on PowerShell I ran: [guid]::NewGuid())
• Add data collector configuration to /etc/delivery/delivery.rb: data_collector['token'] = 'my-guid-here'
• Run sudo delivery-ctl reconfigure

Configure Chef Server to report to Visibility

You’ll also need the Chef Server to report to Visibility. To do this:

• Add the following settings to /etc/opscode/chef-server.rb:

data_collector['root_url'] = 'https://my-automate-server.mycompany.com/data-collector/v0/'
data_collector['token'] = 'TOKEN'

Configure Chef Client to report to Visibility

You’ll need to make sure your chef-client is on a fairly recent version. For me, I need to update chef-client in my infrastructure to 12.15.19 for this to work properly. I had some problems on an earlier version.

Now that we’re on the latest, let’s configure the data_collector on the node in the client.rb:

data_collector.server_url "https://analytics.yourcompany.ncr/data-collector/v0/"
data_collector.token "guid-from-previous-step"

Configure Notification replacement for Analytics

We were taking advantage of the notifications in Chef Analytics and needed a replacement. My colleague has written a slack notifier report handler for Chef that we’re now using.

Initial Thoughts on Visibility

First of all, I’m really impressed with the Chef team for thinking out of the box and getting me on their new platform in a way that works for me. This underscores once again why they’re a great partner: Chef doesn’t show up with an inflexible agenda; they listen, find the right solution, and then execute.

My first impressions of the product are that it looks very nice and clean. I can tell Chef has hired some

UX people. :)

Visibility definitely has room to grow, but it’s an exciting start to a great platform for making Chef operable at scale within the enterprise. While some in the open source community might elect to roll their own reporting platform for Chef-related stuff, to us that’s the path pain and discomfort, because we realize that we’ll never have the funding that Chef has to deliver this. And they like hearing from people like me give them feedback. So to me that’s the best of both worlds.

I don’t like how the Visibility product is tied to workflow, though. I can understand how Chef wants to sell an all-in-one solution, but to me, it’s better to design your products with as little coupling as possible, so they can be independent. From their perspective, it may make sense; keep things simple so your support can be focused in one direction.

I’m really glad I converted my Chef Analytics server to a Visibility server. Hopefully this helps you do the same.
