I’m a huge proponent of policyfiles for managing Chef changes in all of your environments. Let’s talk a little about how we take a policyfile and create a pipeline in Jenkins around it to get it deployed to the right places.

Many environments that aren’t as security-conscious will have a single Chef Server to rule them all, connected to a single CI server. This is the model that Chef Workflow assumes, and it’s a nice situation to be in. In those situations, the pipeline I lay out will be much simpler, but I still recommend following the basic pieces. Since it’s more complicated and therefore covers all the bases, we’ll go for a disconnected, releasable pipeline that can and will traverse the development to operations barrier that many security-minded organizations have.

For our policyfiles pipeline, we create a similar process to our cookbooks:

1. We keep a separate policies git repo for each product group of policies that we have. We don’t keep the policyfiles in the cookbook. This is largely because we want to have our own pipeline for policies that is unrelated to the cookbook pipeline. The cookbook pipeline will promote a cookbook to a supermarket, and the policy will pull the cookbook from that supermarket. This creates two separate processes that have a beginning and end, but are disconnected, so allow for independence. This is a critical aspect to designing any pipeline, and one I’ll blog about in the near future.
2. We have a rakefile for doing tasks that can be done locally on a developer machine
3. We then put that into a pipeline with a Jenkinsfile.

Let’s first look at the rakefile:

Policyfile Rakefile

require 'rake/clean'
require 'rake/packagetask'
def product_name
  'myproduct'
end

def policies
  FileList["#{product_name}-*.rb"]
end

def policies_version(build_number)
  "1.#{build_number}.0"
end

def archive_name
  build_number = ENV['BUILD_ID']
  if build_number.nil?
    "#{product_name}_policies.zip"
  else
    "#{product_name}_policies_#{policies_version(build_number)}.zip"
  end
end

task :default => [:compile_policies]

desc "compiles all policies"
task :compile_policies do
  rm Dir.glob('*.lock.json')
  policies.each do |policyfile|
    sh 'chef', 'install', policyfile
  end
end

directory 'staging'

CLEAN.include('staging')
CLEAN.include('*.zip')

desc "Exports all policies to archives and stages them in the archive folder"
task :export_policies => 'staging' do
  policies.each do |policyfile|
    sh 'chef', 'export', policyfile, 'staging', '-a'
  end
end

require 'os'

task :stage => [:clean, 'staging', :export_policies] do
  cp 'deploy.ps1', 'staging'
  cp 'psake.psm1', 'staging'
  cp 'psake.psd1', 'staging'
  cp 'psake.ps1', 'staging'
end

task :package => [:stage] do
  cd('staging') do
    if OS.windows?
      sh 'C:\Program Files\7-Zip\7z.exe', 'a', '-tzip', archive_name, '*.*', '-x!*.zip'
    else
      sh 'zip', '-r', archive_name, '.', '-x', '*.zip'
    end
  end
end

Let’s unpack this a little bit. Here’s what’s going on:

1. compile_policies will run chef install against all files that have the pattern myproduct-*.rb. So it basically generates the Policyfile.lock.json for all the policies in the repo.
2. export_policies will export all policies to a tgz file with chef export command.
3. stage will stage all the things that are to be packaged into a staging folder including the deployment scripts written in psake (more on that in the next post).
4. package will package the tgz file and the deployment scripts into a package

Policyfile Jenkinsfile

Now that we have a rakefile that can do the work we need, now it’s time to get that into a Jenkinsfile to describe the pipeline. The pipeline will create a package of all policyfile archives and put them, with the script that will deploy them, on our artifactory server. Here’s an example:

#!/usr/bin/env groovy
def repository = 'myproduct-policies'
def workingDirectory = "policies/${repository}"
// the current branch that is being built
def currentBranch = env.BRANCH_NAME
def execute(command){
  ansiColor('xterm'){
    bat command
  }
}
stage('Checkout') {
  node('windows') {
    checkout([$class: 'GitSCM',
              branches: scm.branches,
              doGenerateSubmoduleConfigurations: scm.doGenerateSubmoduleConfigurations,
              extensions: scm.extensions + [[$class: 'RelativeTargetDirectory',
                            relativeTargetDir: workingDirectory], [$class: 'LocalBranch', localBranch: currentBranch]],
              userRemoteConfigs: scm.userRemoteConfigs
     ])
    dir(workingDirectory) {
      execute('rake -t clean')
    }
    stash name: 'everything',
          includes: '**'
  }
}
stage('Compile') {
  node('windows') {
    unstash 'everything'
    dir(workingDirectory) {
      execute('rake -t compile_policies')
      try {
        execute('git add *.lock.json')
        execute("git commit -m \"Automatically Compiled Policyfiles\"")
        withCredentials([[$class: 'UsernamePasswordMultiBinding', credentialsId: 'abcYOUR_GUID_HERE123', usernameVariable: 'GIT_USERNAME', passwordVariable: 'GIT_PASSWORD']]) {
          execute("git push https://${env.GIT_USERNAME}:${env.GIT_PASSWORD}@almgit.ncr.com/scm/chef/${repository}.git ${currentBranch}")
        }
      }
      catch(error) {
        echo "Nothing to commit because of error: ${error}, so skipping pushing"
      }
    }
    stash name: 'compiled',
          includes: '**'
  }
}
stage('Package') {
  node('windows') {
    unstash 'compiled'
    dir(workingDirectory) {
      execute('rake -t package')
      archiveArtifacts 'staging/*.zip'
    }
  }
}
stage('Publish') {
  node('windows') {
    unstash 'compiled'
    dir(workingDirectory) {
      execute('jfrog.exe rt upload "staging\\\\*.zip" myproduct-repo/myproduct-policies/')
    }
  }
}

Here is a description of all the stages:

You can see a pattern here with the pipelines from the earlier post on cookbook build and cookbook pipelines. They rely on script that can run locally, then end up being deployed to something that is a source of the next step in the process. More on that in the next post: how we deploy these policies to a Chef Server and reconverge the nodes.

Conclusion

Hopefully you’re starting to see the pattern I use when designing a pipeline element in my Chef Pipeline. Everything has a starting point and a destination. Every pipeline segment will take a stable input and put it into an even more stable location at the end. It all flows together very quickly and then allows for quick changes that can flow to production.
